4 Chamber Diaphragm Pump 403 Series

4 Chamber Diaphragm Pump 403 Series

VOLTAG

12V/24V/115V/220V

OPEN FLOW

3.0GPM / 11.5LPM

SHUT-OFF PRESSURE

55PSI/3.8BAR

PRIMING CAPABILITIES

6 feet (1.8 m) suction lift

MAX RECOMMENDED TEMPERATURE

140° F (60° C) Max

MATERIAL

EPDM(Valves)/ Santoprene(Diaphragm)

PORTS

1/2″-14 MNPT

Share to

Product Description

MORE FEATURES BENEFITS

Continuous duty
Up to 3.0 GPM
Self priming
Run dry safe
Quiet operation
On-demand use
Industry Standard mounting pattern
Completely rubber mounting-base
Internal bypass technology reduces cycling
16 AWG, 11″(27.9 cm)long leads
2 Year Warranty
Meets or exceeds RoHS. NSF61. CSA and ISO standards
