Pump Design
Diaphragm Pump
Body Material
Polyamide66
Motor Tape
Permanent-Magnet Motors
Port Size
1/2″(15mm)
Liquid temp
60°C
Typical Applications
This diaphragm pump can be used for liquid circulation, transfer, lift, cleaning, spraying, Irrigation and many other occasions. This pump is built with over-pressure, over-heating protection, and built-in pressure switch automatically starts and stop pump for intermittent work. Low noise, self-priming and running dry for a short time (not more than 30 minutes).
