Pump Design
Diaphragm Pump
Body Material
Polyamide66
Motor Tape
Permanent-Magnet Motors
Port Size
1/2″(15mm)
Liquid temp
60°C
Typical Applications
This diaphragm pump can be used for liquid circulation, transfer, lift, cleaning, spraying, Irrigation and many other occasions. This pump is built with over-pressure, over-heating protection, and built-in pressure switch automatically starts and stop pump for intermittent work. Low noise, self-priming and running dry for a short time (not more than 30 minutes).
We specialize in manufacturing various types of pumps, motors, and drinking water system products for yachts and recreational vehicles. We support OEM and ODM business cooperation models. Our products have passed international professional certifications such as CSA, CE, ROHS, and CCS.
